LCN 4041-DEL-SCUSH-AL 4041 Series Delayed Action Door Closer

Cast Iron Body, Door Closer With Spring Cush Arm, Aluminum (689)
4041 SeriesHeavy Duty Door Closer

The LCN 4041 Series is a non-handed surface mounted door closer. A wide choice of options, mounting accessories and ease of installation offer maximum versatility.

The LCN 4041 Series is a heavy duty door closer designed to be used on aluminium, hollow metal or wood swinging commercial interior/exterior doors and is ideally suited for hospitals, educational, institutional and other high traffic applications.

Performance Features:

• Universal, fully reversible, nonhanded door closer.

• Closer cylinder constructed of high strength cast iron for extra durability.

• Tested to 10,000,000 cycles.

• Fully adjustable 1-6 spring strength to suit door size and site conditions.

• Shipped set to size 3.

• Standard closer offers 3 installation options.
• Regular (Pull side)
• Top Jamb (Pull side)
• Parallel Arm (Push side)

• Independent adjustment valves for adjusting backcheck, closing and latching speeds.

• All adjustment valves are concealed behind the cover to prevent tampering.

• Joints in arms and shoe brackets adapt to uneven mounting surfaces.

• Fast adjust dial (fast accurate spring tension) to help installers accurately adjust the closer to match the conditions of the application. As spring power is adjusted, the size appears on the face of the dial.

• Stick-on template for fast, accurate installation. Cuts installation time in half.

• Closers installed according to LCN installation instructions require minimal periodic maintenance or adjustments.

Specifications: Door Type:

• Timber or Metal

Door Size:

• External Door 610mm – 1219mm
• Internal Door 610mm – 1524mm

Applications:

• Regular – Pull Side Mount
• Parallel Arm – Push Side Mount
• Top Jamb – Push Side Mount

Adjustment Controls:

• Closing Speed
• Latching Speed
• Backcheck

Strength:

• 1-6 Adjustable

Options:

• Hold Open Arm
• Adaptor Plate
• Parallel Arm Drop Plate
• Square Metal Cover

Finish:

• Aluminium
• Satin Stainless Steel
• Polished Stainless Steel

Warranty:

• 10 Years
