Sargent 1538-F-10B 1538 Standard Duty Overhead Concealed Mount

US10B Oxidized Bronze Oil Rubbed. F Friction Type Holds door open.
1530 SeriesStandard Duty Overhead Concealed Mount

SARGENT overhead stops/holders are designed to protea the door and hardware from the abuse commonly found in commercial and institutional applications. With different series that include surface or concealed, standard or heavy duty, SARGENT has a stop/holder for every application.

Features:

• Concealed application for interior single or double acting doors opening to 110°

Three types to choose from:

• “H” Holder; Stops and Holds doors open
• “S” Stop; Stops door only
• “F” Friction Type; Holds door open

• Holder/Stop is concealed with aem and bracket mortised into jamb

Hold-Open With Stop:

• Holds door open for a particular degree from 85° to 110°

• Hold-open feature engages and releases easily by a push or pull action

• Release tension is easily adjustable

Stop Only Type:

• Used to stop door with shock absorber spring

• Protects wall and door

• Maximum door opening 110°

Friction Type:

• Prevents unwanted movement of door

• Not for use with a door closer

• Can be held in any position up to 110°

• Adjustable friction control for varying condition

Specifications: For Doors:

• Interior doors 19″ up to 48″ wide, 1-3/8″ to 1-3/4″ thick, as standard. Available for doors up to 2″ thick, use 31 – option and specify thickness

Finishes:

• 03, 04, 9, 10, l0B, 1 DBE, 1DBL,15, 20D, 26, 26D, and EN, EB, ED EAB, and EP

Fasteners:

• Wood screws, machine screws provided as standard

Options:

• 31- Doors 1-7 /8″ to 2· thick, s1-1ecify door thickness
• 36- Torx Security machine screws. 6 required
• CPC- Clear Powder Coat
• SG- MicroShield – antimicrobial silver-based finish

ANSI/BHMA A 156.8 Grade 1:

• 1530F Seriescomplies to C04531
• 1530H Seriescomplies to C04511
• 1530S Seriescomplies to C04541

UL Classified:

• SARGENT 1530Seriesstopsare ULl0B & l0C classified by Underwriter Laboratories as Miscellaneous Fire Door Accessories
• Note: Stops are not rated. The door and frame carry the fire rating

Accessories:

• Standard screw pack 21 -2019 x finish

• When using vertical rod exit devices and or surface/flush bolts, use caution in choosing the proper size to ensure compatibility

Sizing:

• Actual Width of Door – 19″ – 25″
• Hold-Open with Stop – 1536H
• Stop Only – 1536S
• Friction Stop/Holder – 1536F

• Actual Width of Door – 25-1/8″ – 32-1/2″
• Hold-Open with Stop – 1537H
• Stop Only – 1537S
• Friction Stop/Holder – 1537F

• Actual Width of Door – 32-5/8″ – 40″
• Hold-Open with Stop – 1538H
• Stop Only – 1538S
• Friction Stop/Holder – 1538F

• Actual Width of Door – 40-1 /8″ – 48″
• Hold-Open with Stop – 1539H
• Stop Only – 1539S
• Friction Stop/Holder – 1539F

Sizing For Center Hung Pivots Only:

• Actual Width of Door – 21-1 /4″ – 26-5/8″
• Hold-Open with Stop – 1536H
• Stop Only – 1536S
• Friction Stop/Holder – 1536F

• Actual Width of Door – 26-3/4″ – 32-1/2″
• Hold-Open with Stop – 1537H
• Stop Only – 1537S
• Friction Stop/Holder – 1537F

• Actual Width of Door – 32-5/8″ – 40″
• Hold-Open with Stop – 1538H
• Stop Only – 1538S
• Friction Stop/Holder – 1538F

• Actual Width of Door – 40-1 /8″ – 48″
• Hold-Open with Stop – 1539H
• Stop Only – 1539S
• Friction Stop/Holder – 1539F
